Newport vAPEX2 氙弧灯系统，100 W
概览
The LH300 is more than an aluminum enclosure for the lamp: it contains the ignitor, condensing optics, lamp hour counter, and lamp cooling fan. This model was designed for the 300 W Xenon lamp cartridge, model LHC300, making this solution the most straightforward and simple to use in the Oriel Research Arc Lamp Housing family. Simply install the cartridge, make the necessary electrical connections, secure the door, and power on the lamp. No need to align and focus the lamp, as the output light has already been semi-collimated and ready to couple to any other Oriel Instruments' product such as a monochromator or filter wheel.
Newport vAPEX2 氙弧灯系统，100 W技术参数
灯功率：300 W
输出光束尺寸：27 mm
输出光束：Collimated
准直角：± 1°
透镜材料：UV Fused Silica
透镜透射范围：200 - 2500 nm
光纹波：< 1% RMS
法兰系列尺寸：1.5 Inch
工作温度：15 - 40° C
工作湿度：Non-condensing, up to 30%
重量：5.80 lbs. (2.63 kg)
尺寸：5.25 inch x 7 inch x 12 inch (without base)
