单片聚焦镜-3
单片聚焦镜-3
10.6um/9.4um系列
型号 |
波长 |
直径(mm) |
有效焦距(mm) |
中心厚度(mm) |
边缘厚度(mm) |
玻璃材质 |
产品编码 |
LG-10.6-12-46-ET1.79 |
10.6 |
12 |
46 |
1.96 |
1.79 |
GaAs |
1J960100543 |
LG-10.6-12-50.8-ET2 |
10.6 |
12 |
50.8 |
2.16 |
2 |
GaAs |
1J960100126 |
LZ-10.6-12-63.5-ET2.2-LP |
10.6 |
12 |
63.5 |
2.4 |
2.2 |
ZnSe |
1J960100284 |
LZ-10.6-12.4-63.5-ET2 |
10.6 |
12.4 |
63.5 |
2.6 |
2 |
ZnSe |
1J960100681 |
LZ-10.6-12.5-(-26)-ET2.99 |
10.6 |
12.5 |
-26 |
2.45 |
2.99 |
ZnSe |
1J960100197 |
LZ-10.6-12.7-(-14.4)-ET3 |
10.6 |
12.7 |
-14.4 |
1.98 |
3 |
ZnSe |
1J960100728 |
LZ-10.6-12.7-25.4-ET2 |
10.6 |
12.7 |
25.4 |
2.57 |
2 |
ZnSe |
1J960100691 |
LZ-10.6-12.7-38.1-ET2 |
10.6 |
12.7 |
38.1 |
2.37 |
2 |
ZnSe |
1J960100145 |
LZ-10.6-12.7-38.1-ET2-LP |
10.6 |
12.7 |
38.1 |
2.4 |
2 |
ZnSe |
1J960100176 |
LZ-10.6-12.7-38.1-ET2.1 |
10.6 |
12.7 |
38.1 |
2.5 |
2.1 |
ZnSe |
1J960100045 |
LZ M-10.6-12.7-40-ET 2.15 |
10.6 |
12.7 |
40 |
2.5 |
2.15 |
ZnSe |
1J960100809 |
LZ-10.6-12.7-50.93-ET2.03 |
10.6 |
12.7 |
50.93 |
2.31 |
2.03 |
ZnSe |
1J960100713 |
LZ-10.6-12.7-63.5-ET2 |
10.6 |
12.7 |
63.5 |
2.23 |
2 |
ZnSe |
1J960100772 |
LZ-10.6-12.7-185-ET3 |
10.6 |
12.7 |
185 |
3.08 |
3 |
ZnSe |
1J960100229 |
LZ-10.6-12.7-(-25.4)-ET2.2 |
10.6 |
12.7 |
-25.4 |
1.59 |
2.2 |
ZnSe |
1J960100298 |
LZ-10.6-12.7-(-25.4)-ET2.3 |
10.6 |
12.7 |
-25.4 |
1.73 |
2.3 |
ZnSe |
1J960100350 |
LZ-10.6-12.7-(-38.1)-ET2 |
10.6 |
12.7 |
-38.1 |
1.63 |
2 |
ZnSe |
1J960100757 |
LZ M-10.6-12.7-(-56) -ET 2 |
10.6 |
12.7 |
-56 |
1.75 |
2 |
ZnSe |
1J960100796 |
LZ-10.6-12.7-(-18.5)-ET3 |
10.6 |
12.7 |
-18.5 |
2.18 |
3 |
ZnSe |
1J960100081 |
LZ-10.6-14.5-38.1-ET2 |
10.6 |
14.5 |
38.1 |
3.1 |
2 |
ZnSe |
1J960100275 |
LZ-10.6-15-206-ET2 |
10.6 |
15 |
206 |
2.1 |
2 |
ZnSe |
1J960100187 |
LZ-10.6-15-38.1-ET2-LP |
10.6 |
15 |
38.1 |
2.53 |
2 |
ZnSe |
1J960100466 |
LZ-10.6-15-38.1-ET2 |
10.6 |
15 |
38.1 |
2.53 |
2 |
ZnSe |
1J960100352 |
LZ M-10.6-15-47-ET 2 |
10.6 |
15 |
47 |
2.53 |
2 |
ZnSe |
1J960100612 |
LZ-10.6-15-50.8-ET2-LP |
10.6 |
15 |
50.8 |
2.4 |
2 |
ZnSe |
1J960100025 |
LZ-10.6-15-50.8-ET2 |
10.6 |
15 |
50.8 |
2.4 |
2 |
ZnSe |
1J960100360 |
LZ-10.6-15-63.5-ET2-LP |
10.6 |
15 |
63.5 |
2.32 |
2 |
ZnSe |
1J960100467 |
LZ-10.6-15-76.2-ET2.21-LP |
10.6 |
15 |
76.2 |
2.47 |
2.21 |
ZnSe |
1J960100468 |
LZ-10.6-15-76.2-ET2.21 |
10.6 |
15 |
76.2 |
2.47 |
2.21 |
ZnSe |
1J960100931 |
LZ-10.6-15-101.6-ET2 |
10.6 |
15 |
101.6 |
2.47 |
2 |
ZnSe |
1J960100686 |
LZ-10.6-15-127-ET2 |
10.6 |
15 |
127 |
2.16 |
2 |
ZnSe |
1J960100186 |
LZ M-10.6-15.24-38.1-ET 2 |
10.6 |
15.24 |
38.1 |
2.25 |
2 |
ZnSe |
1J960100760 |
LZ-10.6-15.24-38.1-ET1.5 |
10.6 |
15.24 |
38.1 |
2.05 |
1.5 |
ZnSe |
1J960100002 |
LZ-10.6-15.24-38.1-ET2 |
10.6 |
15.24 |
38.1 |
2.55 |
2 |
ZnSe |
1J960100774 |
LZ-10.6-15.24-50.8-ET2-LP |
10.6 |
15.24 |
50.8 |
2.41 |
2 |
ZnSe |
1J960100026 |
LZ-10.6-15.24-101.6-ET2 |
10.6 |
15.24 |
101.6 |
2.2 |
2 |
ZnSe |
1J960100003 |
LZ-10.6-15.24-(-50.8)-ET2 |
10.6 |
15.24 |
-50.8 |
1.59 |
2 |
ZnSe |
1J960100459 |
LZ-10.6-15.24-(-25.27)-ET4.57 |
10.6 |
15.24 |
-25.27 |
3.74 |
4.57 |
ZnSe |
1J960100714 |
LZ M-10.6-15.8-50.8-ET 2 |
10.6 |
15.8 |
50.8 |
2.45 |
2 |
ZnSe |
1J960100088 |
LZ-10.6-16-25.4-ET2-LP |
10.6 |
16 |
25.4 |
2.9 |
2 |
ZnSe |
1J960100075 |
LZ-10.6-16-25.4-ET2 |
10.6 |
16 |
25.4 |
2.9 |
2 |
ZnSe |
1J960100074 |
LZ-10.6-16-38.1-ET2 |
10.6 |
16 |
38.1 |
2.9 |
2 |
ZnSe |
1J960101040 |
LZ-10.6-16-38.1-ET2-LP |
10.6 |
16 |
38.1 |
2.9 |
2 |
ZnSe |
1J960100225 |
LZ M-10.6-16-47-ET 2 |
10.6 |
16 |
47 |
2.48 |
2 |
ZnSe |
1J960100120 |
LZ M-10.6-16-48.3-ET 2 |
10.6 |
16 |
48.3 |
2.47 |
2 |
ZnSe |
1J960100991 |
LZ M-10.6-16-101.6-ET 2.08 |
10.6 |
16 |
101.6 |
2.3 |
2.08 |
ZnSe |
1J960100785 |
LZ-10.6-17-38.1-ET2 |
10.6 |
17 |
38.1 |
2.3 |
2 |
ZnSe |
1J960100310 |
LZ M-10.6-17-47-ET 2 |
10.6 |
17 |
47 |
2.54 |
2 |
ZnSe |
1J960100119 |
LZ M-10.6-17-50.8-ET 2.4 |
10.6 |
17 |
50.8 |
2.9 |
2.4 |
ZnSe |
1J960100672 |
LZ-10.6-17-50.8-ET2 |
10.6 |
17 |
50.8 |
2.54 |
2 |
ZnSe |
1J960100741 |
LZ M-10.6-17-63.5-ET 2.2 |
10.6 |
17 |
63.5 |
2.4 |
2.2 |
ZnSe |
1J960100705 |
LZ M-10.6-17.5-50.8-ET 2 |
10.6 |
17.5 |
50.8 |
2.54 |
2 |
ZnSe |
1J960100109 |
LZ-10.6-17.5-50.8-ET2-LP |
10.6 |
17.5 |
50.8 |
2.54 |
2 |
ZnSe |
1J960100492 |
LZ-10.6-17.5-50.8-ET2 |
10.6 |
17.5 |
50.8 |
2.54 |
2 |
ZnSe |
1J960100027 |
LZ-10.6-17.5-76.2-ET2.3 |
10.6 |
17.5 |
76.2 |
2.65 |
2.3 |
ZnSe |
1J960100513 |
LZ-10.6-18-25.4-ET2-LP |
10.6 |
18 |
25.4 |
2.54 |
2 |
ZnSe |
1J960100510 |
LZ M-10.6-18-38.1-ET 2 |
10.6 |
18 |
38.1 |
2.75 |
2 |
ZnSe |
1J960100663 |
LZ-10.6-18-38.1-ET2-LP |
10.6 |
18 |
38.1 |
2.54 |
2 |
ZnSe |
1J960100047 |
355nm系列
型号 |
波长 |
直径(mm) |
有效焦距(mm) |
中心厚度(mm) |
边缘厚度(mm) |
玻璃材质 |
产品编码 |
LFS-355-25-94.5-ET 2.98 |
355 |
25 |
94.5 |
4.75 |
2.98 |
F_SILICA |
1Z190300048 |
LFS-355-25-142-ET 2.34 |
355 |
25 |
142 |
3.5 |
2.34 |
F_SILICA |
1Z190300049 |
LFS-355-25.4-120-ET1.58 |
355 |
25.4 |
120 |
3 |
1.58 |
F_SILICA |
1J960400025 |
LFS-355-20-77-ET 3.11 |
355 |
20 |
77 |
4.5 |
3.11 |
F_SILICA |
1J960400030 |
LFS-355-25.4-96.5-ET 2.21 |
355 |
25.4 |
96.5 |
4 |
2.21 |
F_SILICA |
1J960400031 |
1064nm系列
型号 |
波长 |
直径(mm) |
有效焦距(mm) |
中心厚度(mm) |
边缘厚度(mm) |
玻璃材质 |
产品编码 |
LBK-1064-10-30-ET 2 |
1064 |
10 |
30 |
2.85 |
2 |
BK7 |
1J960200208 |
LFS-1064-12-55-ET 2 |
1064 |
12 |
55 |
2.74 |
2 |
F_SILICA |
1J960200147 |
LFS-1064-12-80-ET 2 |
1064 |
12 |
80 |
2.5 |
2 |
F_SILICA |
1J960200148 |
LFS-1064-12-100-ET 2.1 |
1064 |
12 |
100 |
2.5 |
2.1 |
F_SILICA |
1J960200149 |
LFS-1064-15-75-ET 2.5 |
1064 |
15 |
75 |
3.3 |
2.5 |
F_SILICA |
1J960200203 |
LFS-1064-15-(-50) -ET 2.5 |
1064 |
15 |
-50 |
1.22 |
2.5 |
F_SILICA |
1J960200115 |
LBK-1064-15-(-50.8) -ET 3.11 |
1064 |
15 |
-50.8 |
2 |
3.11 |
BK7 |
1J960200217 |
LFS-1064-16-(-56) -ET 6 |
1064 |
16 |
-56 |
5 |
6 |
F_SILICA |
1J960200119 |
LFS-1064-16-(-140) -ET 6.5 |
1064 |
16 |
-140 |
6 |
6.5 |
F_SILICA |
1J960200117 |
LBK-1064-18-30-ET 4.15 |
1064 |
18 |
30 |
7 |
4.15 |
BK7 |
1J960200189 |
LFS-1064-18-55-ET 2 |
1064 |
18 |
55 |
3.65 |
2 |
F_SILICA |
1J960200184 |
LFS-1064-18-90-ET 2 |
1064 |
18 |
90 |
3 |
2 |
F_SILICA |
1J960200183 |
LFS-1064-18-125-ET 2 |
1064 |
18 |
125 |
2.71 |
2 |
F_SILICA |
1J960200182 |
LFS-1064-19-30-ET 2 |
1064 |
19 |
30 |
2.71 |
2 |
F_SILICA |
1J960200125 |
LBK-1064-19.05-54-ET 3 |
1064 |
19.05 |
54 |
4.7 |
3 |
BK7 |
1J960200114 |
LBK-1064-19.05-65-ET 3 |
1064 |
19.05 |
65 |
3.5 |
3 |
BK7 |
1J960200127 |
LBK-1064-20-30-ET 2.28 |
1064 |
20 |
30 |
6 |
2.28 |
BK7 |
1J960200173 |
LBK-1064-20-50.8-ET 2.98 |
1064 |
20 |
50.8 |
5 |
2.98 |
BK7 |
1J960200007 |
LBK-1064-20-61-ET 2.54 |
1064 |
20 |
61 |
4.2 |
2.54 |
BK7 |
1J960200218 |
LBK-1064-20-70-ET 2 |
1064 |
20 |
70 |
3.44 |
2 |
BK7 |
1J960200042 |
LFS-1064-20-70-ET 2.38 |
1064 |
20 |
70 |
4 |
2.38 |
F_SILICA |
1J960200252 |
LFS-1064-20-80-ET 3.55 |
1064 |
20 |
80 |
5 |
3.55 |
F_SILICA |
1J960200116 |
LFS-1064-20-150-ET 6.3 |
1064 |
20 |
150 |
7 |
6.3 |
F_SILICA |
1J960200122 |
LFS-1064-20-210-ET 6.5 |
1064 |
20 |
210 |
7 |
6.5 |
F_SILICA |
1J960200123 |
LFS-1064-20-254-ET 6.6 |
1064 |
20 |
254 |
7 |
6.6 |
F_SILICA |
1J960200124 |
