日本GOYO百万像素镜头

Item No.

Focal
Length

Iris Range

Angle of View
(H x V x D)

MOD

Filter Thread

Dimention
(D X L)

Weight

Note

GMTHR23514MCN

3.5mm

F1.4-16

1/2" 103°34'x76°54'x131°4'

0.2m

-

?31X31.75mm

100g

3mega

GMTHR24514MCN

4.5mm

F1.4-16

1/2" 78°96'x59°41'x98°23'

0.2m

-

?31X29.5mm

100g

3mega

GMHR26012MCN

6.0mm

F1.2-16.0

1/2" 56°2'x43°5'x67°0'

0.1m

M30.5,P=0.5

?34X46mm

110g

-

GMHR26014MCN

6.0mm

F1.4-16.0

1/2" 57°4'x44°3'x72°9'

0.2m

M30.5,P=0.5

?32X37.5mm

70g

-

GMTHR21614MCN

16mm

F1.4-16

1/2" 8.8; 24°x18°x29°7'

0.3m

M25.5,P=0.5

?29X31.5mm

50g

-

Itemo.

Focal
Length

Iris Range

Angle of View
(H x V x D)

MOD

Filter Thread

Dimention
(D X L)

Weight

Note

GMTHR36014MCN

6mm

F1.4-16

2/3" 82°'x61°3'x103°02'

0.1m

-

?30X32.8mm

100g

3mega

GMHR38014MCN-1

8mm

F1.4-16

2/3" 56°6'x43°95'x67°22'

0.1m

M27,P=0.5

?31X41mm

100g

3mega

GMTHR38014MCN

8.25mm

F1.44-16

57°32'x44°29'x68°66'

0.1m

M27.0,P=0.5

?30X47.5mm

85g

3mega

GMXHR38014MCN

8mm

F1.4-22

56°7'x43°8'x68°2'

0.1m

M35.5,P=0.5

37.5X28mm

80g

3mega

GMHR31214MCN-1

12mm

F1.4-16

2/3" 38°25'x29°14'x46°71'

0.15m

M27.0,P=0.5

?31X37mm

100g

3mega

GMTHR31214MCN

12.3mm

F1.45-16

39°59'x30°17'x48°38'

0.1m

M27.0,P=0.5

?30X47.5mm

90g

3mega

GMXHR31218MCN-1

12mm

F1.8-22

40°3'x30°8'x49°3'

0.15m

M35.5,P=0.5

37.5X56.5mm

170g

3mega

GMHR32514MCN-1

25mm

F1.4-16

2/3" 19°57'x14°75'x24°3'

0.2m

M27.0,P=0.5

?33X39.5mm

100g

3mega

GMTHR32514MCN

25.0mm

F1.4-16.0

1/2" 14°6'x11°0'x18°2'

2/3" 20°1'x15°1'x25°0'

0.25m

M25.5,P=0.5

?29X32.0mm

50g

3mega

GMXHR32514MCN

25mm

F1.4-22

2/3" 20°x15°x24°8'

0.2m

M35.5,P=0.5

?37.5X44.5mm

110g

3mega

GMHR33520MCN-1

35mm

F2-Close

2/3" 14°3'x10°5'x17°8'

0.3m

M25.5,P=0.5

?29X40mm

-g

3mega

GMTHR33520MCN

35.0mm

F2.0-22.0

1/2" 10°5'x7°9'x13°1'

2/3" 14°3'x10°5'x17°8'

0.25m

M25.5,P=0.5

?29X39mm

60g

3mega

GMXHR33514MCN-1

35mm

F1.4-22

14°3'x10°8'x17°8'

0.25m

M35.5,P=0.5

37.5X56.5mm

145g

3mega

GMHR35028MCN-1

50mm

F2.8-Close

2/3" 10°x7°5'

0.5m

M25.5,P=0.5

?29x30mm

-g

3mega

GMTHR35028MCN

50.0mm

F2.8-22

1/2" 7°3'x5°5'x9°0'

2/3" 10°0'x7°5'x12°4'

0.5m

M25.5,P=0.5

?29X39.0mm

95g

3mega

Item No.

Focal
Length

Iris Range

Angle of View
(HxVxD)

MOD

Filter Thread

Dimention
(D X L)

Weight

Note

GMTHR46018MCN

6mm

F1.8-22

1" 95.1°x78.7°x104.6°

0.1m

No.

?54x50.3mm

225g

3mega

GMTHR48014MCN

8mm

F1.4-16

1" 79.66°x62.92°x92.4°

0.1m

M55,P=0.75

?57x58.59mm

225g

3mega

GMTHR48014MCN-1

8mm

F1.4-22

1" 79.7°x62.9°x92.6°

0.1m

M55,P=0.75

?57x58mm

220g

5mega

GMTHR412514MCN

12.5mm

F1.4-16

1" 56.45°x42.51°x67.59°

0.1m

M35.5,P=0.5

?43x52.94mm

200g

3mega

GMTHR412514MCN-1

12.5mm

F1.4-22

1" 55.7°x42.7°x67.8°

0.3m

M35.5,P=0.5

?40x52mm

160g

5mega

GMTHR41614MCN

16mm

F1.4-22

1" 44°5'x33°8'x54°6'

0.3m

M35.5,P=0.5

?40x42mm

225g

5mega

GMTHR42514MCN

25mm

F1.4-22

1" 29°x21°9'x36°1'

0.3m

M35.5,P=0.5

?40x42.5mm

225g

5mega

GMTHR43514MCN

35mm

F1.4-22

1" 20°9'x16°0'x26.0°

0.3m

M35.5,P=0.5

?40x42.5mm

225g

5mega

GMTHR45014MCN

50mm

F1.4-16

1" 14°5'x10°92'x18°03'

0.5m

M40.5,P=0.5

?47.5x48mm

225g

3mega

GMHR47518MCN-1

75mm

F1.8-16

1" 9°7'x7°3'x12°0'

1.0m

M46.0,P=0.75

?49x57mm

180g

3mega

Item No.

Focal Length

Iris Range

Angle of View
(H x V x D)

MOD

Filter Thread

Dimention
(D X L)

Weight

GMR5HR181214MCN

12mm

F1.4-22

32°38'X24°58'x39°79'

0.2m

M27,P=0.5

?29.5X35.7mm

57g

Item No.

Focal Length

Iris Range

Angle of View
(H x V x D)

MOD

Filter Thread

Dimention
(DxL)

Weight

GMA5HR38028MCN

8mm

F2.8-22

57°9'X45°0'

0.1m

M49,P=0.75

?51X48.5mm

210g

GMA5HR31218MCN

12mm

F1.8-22

40°3'X30°8'

0.15m

M49,P=0.75

?51X59.0mm

200g

GMR5HR31614MCN

16mm

F1.4-16

30°99'X23°43'X38°29'

0.25mm

M27,P=0.5

?29.5X37.2mm

64g

GM5HR31614MCN

16mm

F1.4 - 22

30°7X23°3'

0.2m

M49,P=0.75

?51X62.5mm

200g

GMB5HR31614MCN

16mm

F1.4-16

30°0X22°7'X37°0'

0.2m

M30.5,P=0.5

?38.5X39.1mm

85g

GMR5HR32514MCN

25mm

F1.4-16

19°98'X15°04'X24°86'

0.25m

M27,P=0.5

?29.5X38.8mm

56g

GM5HR32514MCN

25mm

F1.4 - 22

20°0'X15°0'

0.2m

M49,P=0.75

?51X48.0mm

190g

GMB5HR32514MCN

25mm

F1.4-16

19°6'X14°8'X24°3'

0.2m

M30.5,P=0.5

?38.5X44.0mm

90g

GMR5HR33516MCN

35mm

F1.6-16

14°74'X11°08'X18°37'

0.35m

M27,P=0.5

?29.5X40.8mm

65g

GM5HR33514MCN

35mm

F1.4 - 22

14°3'X10°8'

0.25m

M49,P=0.75

?51X62.0mm

230g

GMR5HR35028MCN

50mm

F2.8-22

10°03'X7°54'X12°52'

0.8m

M27,P=0.5

?29.5X38mm

55g

GMB5HR35028MCN

50mm

F2.8-22

9°6'X7°2'X11°9'

0.2m

M30.5,P=0.5

?38.5X76.0mm

120g

Item No.

Focal Length

Iris Range

Angle of View
(H x V x D)

MOD

Filter Thread

Dimention
(D x L)

Weight

GM6HR38014MCN

8mm

F1.4-16

2/3" 56°6'x43°95'x67°22'

0.1m

M27,P=0.5

?31x41mm

100g

GM6HR31214MCN

12mm

F1.4-16

2/3" 38°25'x29°14'x46°71'

0.15m

M27.0,P=0.5

?31x37mm

100g

GM6HR31614MCN

16mm

F1.4-16

2/3" 30°3'x16°05'x37°33'

0.2m

M27,P=0.5

?33x36.5mm

100g

GM6HR32514MCN

25mm

F1.4-16

2/3" 19°57'x14°75'x24°3'

0.2m

M27.0,P=0.5

?33x39.5mm

100g

GM6HR33520MCN

35mm

F2-Close

2/3" 14°3'x10°5'x17°8'

0.3m

M25.5,P=0.5

?29X40mm

-g

GM6HR35028MCN

50mm

F2.8-Close

2/3" 10°x7°5'

0.5m

M25.5,P=0.5

?29x30mm

-g

Item No.

Focal Length

Iris Range

Angle of View
(H x V x D)

MOD

Filter Thread

Dimention
(D x L)

Weight

GM6HR51614MCN

16mm

F1.4-22

1.1" 48°6'x37°1'

0.3m

M35.5,P=0.5

?40x44.3mm

120g

Item No.

Focal Length

Iris Range

Angle of View
(H x V)

MOD

Filter Thread

Dimention
(D X L)

Weight

GM8MPDN41450MCN

14-50mm

F2.6-16

50°5'x38.0' - 14°5'x11°1'

1.2m

M58,P=0.75

?60x90mm

400g

Item No.

Focal Length

Iris Range

Angle of View
(HxV)

MOD

Filter Thread

Dimention
(DxL)

Weight

GM12HR62520MCN

25mm

F2.0-22

4/3" 40°6'x31°

0.15m

M46,P=0.75

?48x82.7mm

250g

GM12HR63520MCN

35mm

F2.0-22

4/3" 29°6'x22°4'

0.2m

M40.5,P=0.5

?44.6x54.9mm

173g

GM12HR65020MCN

50mm

F2.0-22

4/3" 20°9'x15°7'

0.3m

M40.5,P=0.5

?44.6x53.7mm

170g

Item No.

Focal Length

Iris Range

Angle of View
(HxV)

MOD

Filter Thread

Dimention
(DxL)

Weight

GM12HR58018MCN

8mm

F1.8-22

1.1" 83°5'x66°7'

0.3m

M=77,P=0.75

?80x96.8mm

500g

GM12HR51618MCN

16mm

F1.8-16

1.1" 41°85'x41°85'

0.05m

M49,P=0.75

?51x91.5mm

300g

GM12HR52514MCN

25mm

F1.4-16

1.1" 27°06'x27°06'

0.08m

M52,P=0.75

?55x74.5mm

300g

GM12HR53514MCN

35mm

F1.4-16

1.1" 19°30'x19°30'

0.11m

M46,P=0.75

?51x67.5mm

300g

GM12HR55018MCN

50mm

F1.8-16

1.1" 14°x14°

0.2m

M49,P=0.75

?51x74.5mm

300g

GM12HR57518MCN

75mm

F1.8-16

1.1" 9°35'x9°35'

0.3m

M55,P=0.75

?57.5x116.5mm

300g

Item No.

Focal Length

Iris Range

Angle of View
(H
x
V)

MOD

Filter Thread

Dimention
(D x L)

Weight

GM12HR41216MCN

12mm

F1.6-22

1" 57°1'x44°1'

0.2m

M52,P=0.75

?54x61mm

190g

GM12HR41616MCN

16mm

F1.6-22

1" 44°2'x33°5'

0.35m

M37.5,P=0.5

?47.5x58mm

205g

GM12HR42016MCN

20mm

F1.6-22

1" 36°1'x27°2'

0.45m

M39,P=0.5

?43x55mm

165g

GM12HR42516MCN

25mm

F1.6-22

1" 29°x21°8'

0.45m

M39,P=0.5

?43x52mm

160g

GM12HR43514MCN

35mm

F1.4-22

1" 20°7'x51°6'

0.45m

M39,P=0.5

?43x49mm

155g

Item No.

Focal Length

Iris Range

Angle of View
(H x V)

MOD

Filter Thread

Dimention
(D x L)

Weight

GM12HR30528MCN

5mm

F2.8-22

2/3" 81°54'x65°76'

0.1m

M55,P=0.75

?57x64.5mm

300g

GM12HR38018MCN

8mm

F1.8-22

2/3" 57°45'x44°50'

0.1m

M40.5,P=0.5

?47.5x73.2mm

300g

GM12HR38016MCN

8mm

F1.6-22

2/3" 55°8'x43°3'

0.15m

M40.5,P=0.5

?45x53mm

170g

GM12HR39014MCN-1

9mm

F1.4-Close

2/3" 50°8'x39°3'
1/2" 38°2'x29°1'

0.1m

M46.0,P=0.75

?48x54mm

160g

GM12HR31214MCN

12mm

F1.4-22

2/3" 39°75'x30°35'

0.1m

M37.5,P=0.75

?44.5x62mm

300g

GM12HR31216MCN

12mm

F1.6-22

2/3" 39°8'x30°4'

0.1m

M37.5,P=0.5

?43.2x58.5mm

178g

GM12HR312514MCN-1

12.5mm

F1.4-Close

2/3" 37°8'x28°8'
1/2" 28°x21°2'

0.15m

M46.0,P=0.75

?48x66.8mm

205g

GM12HR31616MCN

16mm

F1.6-22

2/3" 30°8'x23°4'

0.2m

M37.5,P=0.5

?43.2x63.3mm

181g

GM12HR31814MCN-1

18mm

F1.4-Close

2/3" 27°8'x21°
1/2" 20°4'x15°4'

0.2m

M46.0,P=0.75

?48x73.5mm

285g

GM12HR32514MCN

25mm

F1.4-22

2/3" 20°x15°

0.2m

M37.5,P=0.5

?43.2x54.5mm

148g

GM12HR33514MCN

35mm

F1.4-22

2/3" 14°3'x10°8'

0.3m

M37.5,P=0.5

?43.2x56.8mm

156g

GM12HR35018MCN

50mm

F1.8-22

2/3" 10°1'x7°6''x12°6'

0.4m

M37.5,P=0.5

?43.2x58.5mm

173g

GM12HR37520MCN

75mm

F2.0-22

2/3" 6°7'x5°x8°4'

0.9m

M37.5,P=0.5

?45x71.7mm

Item No.

Focal Length

Iris Range

Angle of View
(H x V x D)

MOD

Filter Thread

Dimention
(D X L)

Weight

GMMPZ4411MCN

4.4-11 mm

F1.6-16

1/1.8" 36°7'X28°0'X44°8'
- 76°6'X61°2'X89°4'

0.3m

M43,P=0.75

?45X56.5mm

125g

GMMPZ1040MCN

10-40 mm

F1.6-16

1/1.8" 10°5'X7°9'Xx13°1'
- 39°5'X22°5'X48°3'

0.5m

M49,P=0.75

?51X107mm

290g

Item No.

Focal Length

Iris Range

Angle of View
(H x V x D)

MOD

Filter Thread

Dimention
(D X L)

Weight

GMMPZ1664MCN

16-64 mm

F1.8-16

1" 11°7'X8°8'X14°6'
- 45°9'X34°2'X57°9'

1.0m

M58,P=0.75

?60X125mm

375g
