4-6λ外表面镀膜反射镜
1）备有各种形状和尺寸可选
2）可反射可见光，达90%
3）有关定制尺寸，请
经济实惠的4 - 6λ 外表面镀膜反射镜适用于各种应用。本反射镜备有圆形、方形和矩形的反射镜等形状。矩形的外表面镀膜反射镜适用于需要在45°安装反射镜的应用，以达到90°光线路径弯曲。
4-6λ外表面镀膜反射镜
Common Specifications
表面平整度: |
4 - 6λ |
基底: |
Float Glass |
表面质量: |
80-50 |
?
技术数据
?
尺寸 (mm) |
直径 (mm) |
涂层规格 |
涂层 |
产品号 |
|---|---|---|---|---|
3.0 x 3.0 |
? |
Ravg>95% @ 450 - 650nm |
Enhanced Aluminum |
#31-001 |
- |
5 |
Ravg>95% @ 450 - 650nm |
Enhanced Aluminum |
#27-400 |
- |
6.3 |
Ravg>85% @ 400 - 700nm |
Protected Aluminum |
#32-354 |
- |
9 |
Ravg>85% @ 400 - 700nm |
Protected Aluminum |
#46-647 |
9.0 x 9.0 |
? |
Ravg>85% @ 400 - 700nm |
Protected Aluminum |
#31-004 |
9.5 x 11.2 |
? |
Ravg>85% @ 400 - 700nm |
Protected Aluminum |
#31-418 |
- |
12.5 |
Ravg>95% @ 450 - 650nm |
Enhanced Aluminum |
#27-402 |
- |
12.7 |
Ravg>85% @ 400 - 700nm |
Protected Aluminum |
#69-243 |
12.7 x 12.7 |
? |
Ravg>85% @ 400 - 700nm |
Protected Aluminum |
#69-244 |
12.7 x 18.0 |
? |
Ravg>85% @ 400 - 700nm |
Protected Aluminum |
#83-535 |
- |
15 |
Ravg>85% @ 400 - 700nm |
Protected Aluminum |
#31-006 |
- |
16 |
Ravg>85% @ 400 - 700nm |
Protected Aluminum |
#46-648 |
17.0 x 23.0 |
? |
Ravg>85% @ 400 - 700nm |
Protected Aluminum |
#31-417 |
- |
19 |
Ravg>85% @ 400 - 700nm |
Protected Aluminum |
#46-649 |
19.0 x 19.0 |
? |
Ravg>85% @ 400 - 700nm |
Protected Aluminum |
#46-650 |
21.0 x 26.0 |
? |
Ravg>85% @ 400 - 700nm |
Protected Aluminum |
#40-286 |
22.0 x 22.0 |
? |
Ravg>85% @ 400 - 700nm |
Protected Aluminum |
#32-368 |
22.0 x 29.0 |
? |
Ravg>85% @ 400 - 700nm |
Protected Aluminum |
#31-419 |
- |
25.4 |
Ravg>85% @ 400 - 700nm |
Protected Aluminum |
#69-245 |
25.4 x 25.4 |
? |
Ravg>85% @ 400 - 700nm |
Protected Aluminum |
#69-246 |
25.4 x 35.4 |
? |
Ravg>85% @ 400 - 700nm |
Protected Aluminum |
#83-536 |
- |
26 |
Ravg>85% @ 400 - 700nm |
Protected Aluminum |
#31-009 |
30.0 x 40.0 |
? |
Ravg>85% @ 400 - 700nm |
Protected Aluminum |
#30-429 |
31.0 x 77.0 |
? |
Ravg>85% @ 400 - 700nm |
Protected Aluminum |
#32-366 |
- |
32 |
Ravg>85% @ 400 - 700nm |
Protected Aluminum |
#46-651 |
35.0 x 109.0 |
? |
Ravg>85% @ 400 - 700nm |
Protected Aluminum |
#32-359 |
38.0 x 38.0 |
? |
Ravg>85% @ 400 - 700nm |
Protected Aluminum |
#46-652 |
38.0 x 38.0 |
? |
Ravg>85% @ 400 - 700nm |
Protected Aluminum |
#31-422 |
38.0 x 51.0 |
? |
Ravg>85% @ 400 - 700nm |
Protected Aluminum |
#31-425 |
38.0 x 150.0 |
? |
Ravg>85% @ 400 - 700nm |
Protected Aluminum |
#32-442 |
- |
38.1 |
Ravg>85% @ 400 - 700nm |
Protected Aluminum |
#69-247 |
38.1 x 38.1 |
? |
Ravg>85% @ 400 - 700nm |
Protected Aluminum |
#69-248 |
38.1 x 53.9 |
? |
Ravg>85% @ 400 - 700nm |
Protected Aluminum |
#83-537 |
50.0 x 125.0 |
? |
Ravg>85% @ 400 - 700nm |
Protected Aluminum |
#32-365 |
- |
50.8 |
Ravg>85% @ 400 - 700nm |
Protected Aluminum |
#69-249 |
50.8 x 50.8 |
? |
Ravg>85% @ 400 - 700nm |
Protected Aluminum |
#69-250 |
50.8 x 71.8 |
? |
Ravg>85% @ 400 - 700nm |
Protected Aluminum |
#83-538 |
51.0 x 76.0 |
? |
Ravg>85% @ 400 - 700nm |
Protected Aluminum |
#40-040 |
60.0 x 270.0 |
? |
Ravg>85% @ 400 - 700nm |
Protected Aluminum |
#32-279 |
73.0 x 116.0 |
? |
Ravg>85% @ 400 - 700nm |
Protected Aluminum |
#32-371 |
76.0 x 102.0 |
? |
Ravg>85% @ 400 - 700nm |
Protected Aluminum |
#40-041 |
- |
76.2 |
Ravg>85% @ 400 - 700nm |
Protected Aluminum |
#69-251 |
76.2 x 76.2 |
? |
Ravg>85% @ 400 - 700nm |
Protected Aluminum |
#69-252 |
76.2 x 107.8 |
? |
Ravg>85% @ 400 - 700nm |
Protected Aluminum |
#83-539 |
81.0 x 100.0 |
? |
Ravg>85% @ 400 - 700nm |
Protected Aluminum |
#41-621 |
85.0 x 101.0 |
? |
Ravg>85% @ 400 - 700nm |
Protected Aluminum |
#32-362 |
102.0 x 127.0 |
? |
Ravg>85% @ 400 - 700nm |
Protected Aluminum |
#40-042 |
127.0 x 178.0 |
? |
Ravg>85% @ 400 - 700nm |
Protected Aluminum |
#41-320 |
127.0 x 178.0 |
? |
Ravg>85% @ 400 - 700nm |
Protected Aluminum |
#40-043 |
169.0 x 194.0 |
? |
Ravg>85% @ 400 - 700nm |
Protected Aluminum |
#41-405 |
200.0 x 235.0 |
? |
Ravg>85% @ 400 - 700nm |
Protected Aluminum |
#32-358 |
204.0 x 254.0 |
? |
Ravg>85% @ 400 - 700nm |
Protected Aluminum |
#41-321 |
204.0 x 254.0 |
? |
Ravg>85% @ 400 - 700nm |
Protected Aluminum |
#40-067 |
254.0 x 254.0 |
? |
Ravg>85% @ 400 - 700nm |
Protected Aluminum |
#46-653 |
254.0 x 313.0 |
? |
Ravg>85% @ 400 - 700nm |
Protected Aluminum |
#46-654 |
254.0 x 313.0 |
? |
Ravg>85% @ 400 - 700nm |
Protected Aluminum |
#32-248 |
254.0 x 356.0 |
? |
Ravg>85% @ 400 - 700nm |
Protected Aluminum |
#85-036 |
356.0 x 356.0 |
? |
Ravg>85% @ 400 - 700nm |
Protected Aluminum |
#46-655 |
406.0 x 406.0 |
? |
Ravg>85% @ 400 - 700nm |
Protected Aluminum |
#46-656 |
406.0 x 406.0 |
? |
Ravg>85% @ 400 - 700nm |
Protected Aluminum |
#85-206 |
408.0 x 609.0 |
? |
Ravg>85% @ 400 - 700nm |
Protected Aluminum |
#85-207 |
