荧光滤光片组件
（1）用于荧光成像方面的激发、发射以及二向色滤光片
（2）透射波段透射率>93%，截止带高为OD6，高亮度，高对比度
（3）在单层物质上镀加硬离子溅射膜
（4）容易获得TECHSPEC 预先安装滤波片的立方体
TECHSPEC?荧光滤光片组件在装入荧光显微镜后可明显提高图像的清晰度。通带的高透射率保证了成像亮度，而截止带的深截止则确保了将不需要的光信号滤除在探测器以外。这种滤光片所呈像的信噪比比使用通常使用的阶梯滤光片高。本套滤光片可用于常见的荧光方面的应用。
| Excitation and Emission Filters | Dichroic Filter | ? |
| Size | 25.0mm | 25.2 x 35.6mm |
| Thickness | 3.5mm | 1.05mm |
| Tolerances | ? | ? |
| Size | +0.0/-0.1 | ? |
| Thickness | ±0.1mm | ? |
| Clear Aperture | 22.0mm | 22.0 x 30.0mm |
| Transmitted Wavefront (RMS) | <λ/4 | ? |
| Angle of Incidence | 0.0° ±5.0° | 45.0° ±5.0° |
| Compatible Microscopes | Most common Nikon, Olympus, and Zeiss Microscopes | ? |
标题 |
产品号 |
Fluorescence Filter Set for Cyan Fluorescence Protein (CFP) |
#67-002 |
Fluorescence Filter Set for Green Fluorescence Protein (GFP) |
#67-003 |
Fluorescence Filter Set for FITC Fluorescein |
#67-004 |
Fluorescence Filter Set for Yellow Fluorescence Protein (YFP) |
#67-005 |
Fluorescence Filter Set for Cy3 Fluorescence Dye |
#67-006 |
Fluorescence Filter Set for TRITC Rhodamine Dye |
#67-007 |
Fluorescence Filter Set for Texas Red Fluorescence Dye |
#67-008 |
Fluorescence Filter Set for mCherry Fluorescence Protein |
#67-009 |
Fluorescence Filter Set for CY5 Fluorescence Dye |
#67-010 |
Fluorescence Filter Set for CY5.5 Fluorescence Dye |
#67-011 |
Fluorescence Filter Set for DAPI (High Brightness) |
#86-370 |
Fluorescence Filter Set for DAPI (High Contrast) |
#86-371 |
Fluorescence Filter Set for Lucifer Yellow |
#86-372 |
Fluorescence Filter Set for SpectrumGreen |
#86-373 |
Fluorescence Filter Set for Qdot 525 |
#86-374 |
Fluorescence Filter Set for Qdot 605 |
#86-375 |
Fluorescence Filter Set for Qdot 625 |
#86-376 |
Fluorescence Filter Set for Qdot 655 |
#86-377 |
Fluorescence Filter Set for SpectrumGold |
#86-378 |
Fluorescence Filter Set for SpectrumOrange |
#86-379 |
Fluorescence Filter Set for SpectrumRed |
#86-380 |
Fluorescence Filter Set for Indocyanine Green (ICG) |
#86-381 |
订购信息：
Fluorescence Filter Set for Cyan Fluorescence Protein (CFP)
库存#67-002技术参数与相关资料
| 兼容的荧光团 | CFP |
| 激发波长 (nm) | 426 - 450 |
| 发射波长 (nm) | 502 - 538 |
| 二向色镜片转换处波长(nm) | 458 |
| 激发滤光片 | #67-026 |
| 受激滤光片 | #67-028 |
| 二向色滤光片 | #67-078 |
| 基底 | Fused Silica |
| 类型 | Fluorescence Filter Kit |
| 波长范围 (nm) | 425 - 538 |
| 涂层 | Hard Coated |
| 生产商 | EO |
| RoHS | 符合标准 |
Fluorescence Filter Set for Green Fluorescence Protein (GFP)
库存#67-003技术参数与相关资料
| 兼容的荧光团 | GFP |
| 激发波长 (nm) | 457 - 487 |
| 发射波长 (nm) | 502 - 538 |
| 二向色镜片转换处波长(nm) | 495 |
| 激发滤光片 | #67-027 |
| 受激滤光片 | #67-030 |
| 二向色滤光片 | #67-079 |
| 基底 | Fused Silica |
| 类型 | Fluorescence Filter Kit |
| 波长范围 (nm) | 457 - 538 |
| 涂层 | Hard Coated |
| 生产商 | EO |
| RoHS | 符合标准 |
Fluorescence Filter Set for Yellow Fluorescence Protein (YFP)
库存#67-005技术参数与相关资料
| 兼容的荧光团 | YPF |
| 激发波长 (nm) | 488 - 512 |
| 发射波长 (nm) | 532 - 554 |
| 二向色镜片转换处波长(nm) | 520 |
| 激发滤光片 | #67-029 |
| 受激滤光片 | #67-032 |
| 二向色滤光片 | #67-081 |
| 基底 | Fused Silica |
| 类型 | Fluorescence Filter Kit |
| 波长范围 (nm) | 488 - 554 |
| 涂层 | Hard Coated |
| 生产商 | EO |
| RoHS | 符合标准 |
Fluorescence Filter Set for mCherry Fluorescence Protein
库存#67-009技术参数与相关资料
| 兼容的荧光团 | mCherry |
| 激发波长 (nm) | 542 - 582 |
| 发射波长 (nm) | 603 - 678 |
| 二向色镜片转换处波长(nm) | 593 |
| 激发滤光片 | #67-033 |
| 受激滤光片 | #67-036 |
| 二向色滤光片 | #67-083 |
| 基底 | Fused Silica |
| 类型 | Fluorescence Filter Kit |
| 波长范围 (nm) | 542 - 678 |
| 涂层 | Hard Coated |
| 生产商 | EO |
| RoHS | 符合标准 |
Fluorescence Filter Set for DAPI (High Brightness)
库存#86-370 技术参数与相关资料
| 兼容的荧光团 | DAPI (High Brightness) |
| 激发波长 (nm) | 352 - 402 |
| 发射波长 (nm) | 417 - 477 |
| 二向色镜片转换处波长(nm) | 409 |
| 激发滤光片 | #84-093 |
| 受激滤光片 | #84-095 |
| 二向色滤光片 | #86-330 |
| 基底 | Fused Silica |
| 类型 | Fluorescence Filter Kit |
| 波长范围 (nm) | 352 - 477 |
| 涂层 | Hard Coated |
| 生产商 | EO |
| RoHS | 符合标准 |
