可视和NIR平板分光器
?提供多种分光率
?提供可视及NIR覆膜选择
?第二面镀多层减反膜
?同时提供C接口平板分光器
作为双重放大成像系统以及组合低倍率激光光束的理想选择，TECHSPEC? 可视和NIR平板分光器能够提供经抛光的优质光学等级玻璃的佳组合，并将基片厚度降低。宽频介电覆膜能够提供大的光通量，是实现鬼影小化的理想选择，同时与金属膜层相比，其能量损失也小得多。背面使用多层防反射（AR）覆膜，将每一种波长范围内的背部反射降低1.0%以下。备注：这些分光器专为45°入射角和随机偏振设计。
Common Specifications
表面平整度: |
1λ |
基底: |
N-BK7 |
入射角 (°): |
45 |
技术数据
订购信息
直径 (mm) |
尺寸 (mm) |
反射/透射比 (R/T) |
波长范围 (nm) |
产品号 |
|---|---|---|---|---|
12.5 |
- |
20/80 |
400 - 700 |
#68-363 |
12.5 |
- |
30/70 |
400 - 700 |
#48-388 |
12.5 |
- |
40/60 |
400 - 700 |
#68-381 |
12.5 |
- |
50/50 |
400 - 700 |
#47-021 |
12.5 |
- |
60/40 |
400 - 700 |
#68-399 |
12.5 |
- |
70/30 |
400 - 700 |
#48-394 |
12.5 |
- |
80/20 |
400 - 700 |
#68-417 |
? |
12.5 x 17.5 |
20/80 |
400 - 700 |
#68-365 |
? |
12.5 x 17.5 |
30/70 |
400 - 700 |
#48-390 |
? |
12.5 x 17.5 |
40/60 |
400 - 700 |
#68-383 |
? |
12.5 x 17.5 |
50/50 |
400 - 700 |
#47-022 |
? |
12.5 x 17.5 |
60/40 |
400 - 700 |
#68-401 |
? |
12.5 x 17.5 |
70/30 |
400 - 700 |
#48-396 |
? |
- |
80/20 |
400 - 700 |
#68-419 |
25 |
- |
20/80 |
400 - 700 |
#68-367 |
25 |
- |
30/70 |
400 - 700 |
#47-240 |
25 |
- |
40/60 |
400 - 700 |
#68-385 |
25 |
- |
50/50 |
400 - 700 |
#45-852 |
25 |
- |
60/40 |
400 - 700 |
#68-403 |
25 |
- |
70/30 |
400 - 700 |
#48-398 |
25 |
- |
80/20 |
400 - 700 |
#68-421 |
? |
25.0 x 25.0 |
20/80 |
400 - 700 |
#68-369 |
? |
25.0 x 25.0 |
30/70 |
400 - 700 |
#48-898 |
? |
25.0 x 25.0 |
40/60 |
400 - 700 |
#68-387 |
? |
25.0 x 25.0 |
50/50 |
400 - 700 |
#48-902 |
? |
25.0 x 25.0 |
60/40 |
400 - 700 |
#68-405 |
? |
25.0 x 25.0 |
70/30 |
400 - 700 |
#48-906 |
? |
25.0 x 25.0 |
80/20 |
400 - 700 |
#68-423 |
? |
25.0 x 38.0 |
20/80 |
400 - 700 |
#68-371 |
? |
25.0 x 38.0 |
30/70 |
400 - 700 |
#48-392 |
? |
25.0 x 38.0 |
40/60 |
400 - 700 |
#68-389 |
? |
25.0 x 38.0 |
60/40 |
400 - 700 |
#68-407 |
? |
25.0 x 38.0 |
50/50 |
400 - 700 |
#47-023 |
? |
25.0 x 38.0 |
70/30 |
400 - 700 |
#48-400 |
? |
25.0 x 38.0 |
80/20 |
400 - 700 |
#68-425 |
? |
35.0 x 35.0 |
20/80 |
400 - 700 |
#68-373 |
? |
35.0 x 35.0 |
30/70 |
400 - 700 |
#49-752 |
? |
35.0 x 35.0 |
40/60 |
400 - 700 |
#68-391 |
? |
35.0 x 35.0 |
50/50 |
400 - 700 |
#49-754 |
? |
35.0 x 35.0 |
60/40 |
400 - 700 |
#68-409 |
? |
35.0 x 35.0 |
70/30 |
400 - 700 |
#49-756 |
? |
35.0 x 35.0 |
80/20 |
400 - 700 |
#68-427 |
? |
50.0 x 50.0 |
30/70 |
400 - 700 |
#47-241 |
? |
50.0 x 50.0 |
50/50 |
400 - 700 |
#45-854 |
? |
50.0 x 50.0 |
20/80 |
400 - 700 |
#68-375 |
? |
50.0 x 50.0 |
40/60 |
400 - 700 |
#68-393 |
? |
50.0 x 50.0 |
60/40 |
400 - 700 |
#68-411 |
? |
50.0 x 50.0 |
70/30 |
400 - 700 |
#48-402 |
? |
50.0 x 50.0 |
80/20 |
400 - 700 |
#68-429 |
? |
50.0 x 75.0 |
20/80 |
400 - 700 |
#68-377 |
? |
50.0 x 75.0 |
30/70 |
400 - 700 |
#62-881 |
? |
50.0 x 75.0 |
40/60 |
400 - 700 |
#68-395 |
? |
50.0 x 75.0 |
50/50 |
400 - 700 |
#62-882 |
? |
50.0 x 75.0 |
60/40 |
400 - 700 |
#68-413 |
? |
50.0 x 75.0 |
70/30 |
400 - 700 |
#62-883 |
? |
50.0 x 75.0 |
80/20 |
400 - 700 |
#68-431 |
? |
75.0 x 75.0 |
20/80 |
400 - 700 |
#68-379 |
? |
75.0 x 75.0 |
30/70 |
400 - 700 |
#48-900 |
? |
75.0 x 75.0 |
40/60 |
400 - 700 |
#68-397 |
? |
75.0 x 75.0 |
50/50 |
400 - 700 |
#48-904 |
? |
75.0 x 75.0 |
60/40 |
400 - 700 |
#68-415 |
? |
75.0 x 75.0 |
70/30 |
400 - 700 |
#48-908 |
? |
75.0 x 75.0 |
80/20 |
400 - 700 |
#68-433 |
12.5 |
- |
20/80 |
700 - 1100 |
#68-364 |
12.5 |
- |
30/70 |
700 - 1100 |
#48-389 |
12.5 |
- |
40/60 |
700 - 1100 |
#68-382 |
12.5 |
- |
50/50 |
700 - 1100 |
#47-024 |
12.5 |
- |
60/40 |
700 - 1100 |
#68-400 |
12.5 |
- |
70/30 |
700 - 1100 |
#48-395 |
12.5 |
- |
80/20 |
700 - 1100 |
#68-418 |
? |
12.5 x 17.5 |
20/80 |
700 - 1100 |
#68-366 |
? |
12.5 x 17.5 |
30/70 |
700 - 1100 |
#48-391 |
? |
12.5 x 17.5 |
40/60 |
700 - 1100 |
#68-384 |
? |
12.5 x 17.5 |
50/50 |
700 - 1100 |
#47-025 |
? |
12.5 x 17.5 |
60/40 |
700 - 1100 |
#68-402 |
? |
12.5 x 17.5 |
70/30 |
700 - 1100 |
#48-397 |
? |
12.5 x 17.5 |
80/20 |
700 - 1100 |
#68-420 |
25 |
- |
20/80 |
700 - 1100 |
#68-368 |
25 |
- |
30/70 |
700 - 1100 |
#47-242 |
25 |
- |
40/60 |
700 - 1100 |
#68-386 |
25 |
- |
50/50 |
700 - 1100 |
#45-853 |
25 |
- |
60/40 |
700 - 1100 |
#68-404 |
25 |
- |
70/30 |
700 - 1100 |
#48-399 |
25 |
- |
80/20 |
700 - 1100 |
#68-422 |
? |
25.0 x 25.0 |
20/80 |
700 - 1100 |
#68-370 |
? |
25.0 x 25.0 |
30/70 |
700 - 1100 |
#48-899 |
? |
25.0 x 25.0 |
40/60 |
700 - 1100 |
#68-388 |
? |
25.0 x 25.0 |
50/50 |
700 - 1100 |
#48-903 |
? |
25.0 x 25.0 |
60/40 |
700 - 1100 |
#68-406 |
? |
25.0 x 25.0 |
70/30 |
700 - 1100 |
#48-907 |
? |
25.0 x 25.0 |
80/20 |
700 - 1100 |
#68-424 |
? |
25.0 x 38.0 |
20/80 |
700 - 1100 |
#68-372 |
? |
25.0 x 38.0 |
30/70 |
700 - 1100 |
#48-393 |
? |
25.0 x 38.0 |
40/60 |
700 - 1100 |
#68-390 |
? |
25.0 x 38.0 |
50/50 |
700 - 1100 |
#47-026 |
? |
25.0 x 38.0 |
60/40 |
700 - 1100 |
#68-408 |
? |
25.0 x 38.0 |
70/30 |
700 - 1100 |
#48-401 |
? |
25.0 x 38.0 |
80/20 |
700 - 1100 |
#68-426 |
? |
35.0 x 35.0 |
20/80 |
700 - 1100 |
#68-374 |
? |
35.0 x 35.0 |
30/70 |
700 - 1100 |
#49-753 |
? |
35.0 x 35.0 |
40/60 |
700 - 1100 |
#68-392 |
? |
35.0 x 35.0 |
50/50 |
700 - 1100 |
#49-755 |
? |
35.0 x 35.0 |
60/40 |
700 - 1100 |
#68-410 |
? |
35.0 x 35.0 |
70/30 |
700 - 1100 |
#49-757 |
? |
35.0 x 35.0 |
80/20 |
700 - 1100 |
#68-428 |
? |
50.0 x 50.0 |
30/70 |
700 - 1100 |
#47-243 |
? |
50.0 x 50.0 |
50/50 |
700 - 1100 |
#45-855 |
? |
50.0 x 50.0 |
20/80 |
700 - 1100 |
#68-376 |
? |
50.0 x 50.0 |
40/60 |
700 - 1100 |
#68-394 |
? |
50.0 x 50.0 |
60/40 |
700 - 1100 |
#68-412 |
? |
50.0 x 50.0 |
70/30 |
700 - 1100 |
#48-403 |
? |
50.0 x 50.0 |
80/20 |
700 - 1100 |
#68-430 |
? |
50.0 x 75.0 |
20/80 |
700 - 1100 |
#68-378 |
? |
50.0 x 75.0 |
30/70 |
700 - 1100 |
#62-884 |
? |
50.0 x 75.0 |
40/60 |
700 - 1100 |
#68-396 |
? |
50.0 x 75.0 |
50/50 |
700 - 1100 |
#62-885 |
? |
50.0 x 75.0 |
60/40 |
700 - 1100 |
#68-414 |
? |
50.0 x 75.0 |
70/30 |
700 - 1100 |
#62-886 |
? |
50.0 x 75.0 |
80/20 |
700 - 1100 |
#68-432 |
? |
75.0 x 75.0 |
20/80 |
700 - 1100 |
#68-380 |
? |
75.0 x 75.0 |
30/70 |
700 - 1100 |
#48-901 |
? |
75.0 x 75.0 |
40/60 |
700 - 1100 |
#68-398 |
? |
75.0 x 75.0 |
50/50 |
700 - 1100 |
#48-905 |
? |
75.0 x 75.0 |
60/40 |
700 - 1100 |
#68-416 |
? |
75.0 x 75.0 |
70/30 |
700 - 1100 |
#48-909 |
? |
75.0 x 75.0 |
80/20 |
700 - 1100 |
#68-434 |
附件
标题 |
产品号 |
|---|---|
Visible Plate Beamsplitter Kit, 25mm Diameter |
#83-388 |
Near Infrared Plate Beamsplitter Kit, 25mm Diameter |
#83-956 |
