90° 反射镜
Protected Gold and Enhanced Aluminum 90° Specialty Mirrors
以180° 将输入图像分成两个不同的路径
备有各种尺寸以及带宽镀膜产品
另外也备有可选的额外
直角棱镜
角度容差（弧分）: |
±2 |
倒角: |
Protective bevel as needed |
有效孔径 (%): |
90.00 |
镀膜类型: |
Metal |
尺寸容差 (mm): |
±0.1 |
基底: |
N-BK7 |
表面质量: |
40-20 |
TECHSPEC? 90° 反射镜是由在两个直角边镀反射膜，而在斜面上不镀膜的直角棱镜形成的。两个反射表面形成一个的90° 角，可将单个成像镜头的图像分成两个，分别用在两个不同的相机上，或者将两个图像合成在一个相机中。
产品信息
| CA (mm) | 支脚长度(mm) | 斜边长度(mm) | 涂层 | 产品编码 |
| 4.6 | 5.0 | 7.1 | Enhanced Aluminum (450-650nm) | #49-412 |
| 9.6 | 10.0 | 14.1 | Enhanced Aluminum (450-650nm) | #47-004 |
| 14.6 | 15.0 | 21.2 | Enhanced Aluminum (450-650nm) | #49-413 |
| 19.4 | 20.0 | 28.3 | Enhanced Aluminum (450-650nm) | #49-414 |
| 24.4 | 25.0 | 35.4 | Enhanced Aluminum (450-650nm) | #47-005 |
| 49.4 | 50.0 | 70.7 | Enhanced Aluminum (450-650nm) | #47-006 |
| 73.5 | 75.0 | 106.1 | Enhanced Aluminum (450-650nm) | #47-309 |
| 4.6 | 5.0 | 7.1 | Protected Gold (700-10000nm) | #65-847 |
| 9.0 | 10.0 | 14.1 | Protected Gold (700-10000nm) | #47-237 |
| 14.6 | 15.0 | 21.2 | Protected Gold (700-10000nm) | #65-848 |
| 19.4 | 20.0 | 28.3 | Protected Gold (700-10000nm) | #65-849 |
| 24.0 | 25.0 | 35.4 | Protected Gold (700-10000nm) | #47-238 |
| 49.0 | 50.0 | 70.7 | Protected Gold (700-10000nm) | #47-239 |
| 73.5 | 75.0 | 106.1 | Protected Gold (700-10000nm) | #47-310 |
| 4.6 | 5.0 | 7.1 | Protected Silver (450-10000nm) | #21-185 |
| 9.0 | 10.0 | 14.1 | Protected Silver (450-10000nm) | #21-186 |
| 14.6 | 15.0 | 21.2 | Protected Silver (450-10000nm) | #21-187 |
| 19.4 | 20.0 | 28.3 | Protected Silver (450-10000nm) | #21-188 |
| 24.0 | 25.0 | 35.4 | Protected Silver (450-10000nm) | #21-189 |
| 49.0 | 50.0 | 70.7 | Protected Silver (450-10000nm) | #21-190 |
| 73.5 | 75.0 | 106.1 | Protected Silver (450-10000nm) | #21-191 |
技术数据
| Stock No. | A | B | C |
| #49-412 | 5mm | 7mm | 5mm |
| #65-847 | |||
| #47-004 | 10mm | 14.1mm | 10mm |
| #47-237 | |||
| #49-413 | 15mm | 21.2mm | 15mm |
| #65-848 | |||
| #49-414 | 20mm | 28.3mm | 20mm |
| #65-849 | |||
| #47-005 | 25mm | 35.4mm | 25mm |
| #47-238 | |||
| #47-006 | 50mm | 70.7mm | 50mm |
| #47-239 | |||
| #47-309 | 75mm | 106.1mm | 75mm |
| #47-310 |
