PixeLINK? USB 2.0 Microscopy Cameras
1）非常适合用于显微方面
2）功能包括实时测量和覆盖能力
3）分辨率超过660万像素
4）也可用到FireWire.a?版本
用于显微系统的PixeLINK?相机非常适用于成像方面的需求，本品设计用在显微镜的顶端，能够用在各种显微系统上。随机携带的软件带实时测量和图像覆盖功能，比如可方便十字线对齐图像。也可慢速拍摄，并以各种视频格式输出(AVI, MPG, MPEG, and MOV)。
?
型号 |
分辨率 (MegaPixels) |
像素 (H x V) |
类型 |
产品号 |
PL-B623 |
3 |
2048 x 1536 |
Color Camera |
#64-236 |
PL-B625 |
5 |
2592 x 1944 |
Color Camera |
#64-237 |
PL-B681 |
1.3 |
1280 x 1024 |
Color Camera |
#64-235 |
PL-B871 |
1.4 |
1392 x 1040 |
Color Camera |
#64-231 |
PL-B873 |
2 |
1600 x 1200 |
Color Camera |
#64-233 |
Software Specifications |
μScope Essentials |
μScope |
PixeLINK? API Control |
|
|
Line Profiling: Single, Multiple, Parallel and Polyline Commands Provide Gray/Red/Green/Blue Intensity Values for Specific Lines within an Image. The Profile Data of Each Pixel on the Line Can Be Exported to Microsoft? Excel?. |
|
|
Multiple Image File Formats: jpg, jpeg, tif, tiff, bmp, gif, pcx, tga, mpg, mpeg, avi, mov, img, rpt, txt |
|
|
Overlay: Crosshair, Grid Mask, Image, Marker |
|
|
Image: Mode Change, Clone, Crop, ROI, Resize, Rotate |
|
|
Zoom Control: 100 - 1600% and Fit to Window Options |
|
|
Annotation: Line, Arrow, Polyline, Spline, Rectangle, Ellipse, Text |
|
|
Image Sequence Control |
|
|
Image Editing: Undo, Redo, Copy, Paste, Paste New, Delete, Delete All, Annotate, Image Information |
|
|
Multiple Window Configurations |
|
|
Export to Excel?: Images with Measurement, Calibration, Annotations, Measurement Data, Statistics, and Chart |
|
|
Measurement Parameters: Area, Max Length, Line Length, Center x and y, Angle |
|
|
Live Measurement and Overlay: Perform Measurements on the Live Preview Image, Using the Crosshair or Grid Masks to Center and Count. The Grid Masks include Calibration Data. |
|
|
Dynamic User Interface |
|
|
Manual Calibration |
|
|
Report Generator: Create, Insert Images and OLE Objects |
|
|
Manual Measurement Tools: 3-Point Circle Functionality, npoint Circle Measurement Functionality, Parallel Line Distance Measurement, Perpendicular Distance Measurement and Object Distance Measurement, Zoom-In Window |
|
|
Time Lapse Capture and Movie File Production with Crosshair on Live Preview |
|
|
Calibration Marker (Scale Bar) Can Be Placed on the Live Preview Image and Burned in Automatically |
|
|
Multiple ROI: Shapes and Copy, Paste, Crop ROI |
|
|
Image Processing: manual brightness, contrast, gamma, background subtraction, histogram, clone, crop, ROI, resize, rotate, split, image mode change, grayscale, RGB, HSB, YUV pseudo color view |
|
|
Auto and Semi-Auto Calibration |
|
|
Profile: Straight line, Polyline, Parallel Line, Select and Change |
|
?
PL-B623 Color USB CMOS Camera for Microscopy
库存#64-236技术参数与相关资料
成像设备 |
ON Semi MT9T001 |
传感器类型 |
Progressive Scan CMOS |
感应区域，H x V (mm) |
6.6 x 4.9 |
像素 (H x V) |
2048 x 1536 |
像素大小，H x V (μm) |
3.2 x 3.2 |
像素深度 |
8/10 bit |
帧频 (fps) |
12 |
电子快门 |
0.1ms - 2s |
快门类型 |
Rolling |
信噪比 (dB) |
>60 |
摄像机控制 |
Via Software |
同步 |
External or Via Software |
视频输出 |
USB 2.0 |
振动额定值 |
300 G & 20 G (10 Hz - 2 KHz) |
震动额定值 |
50 G |
工作温度 (°C) |
0 to +50 |
功率要求 |
Via?#63-237?USB 2.0 Cable (Sold Separay) |
支架 |
C-Mount |
重量 (g) |
204 |
类型 |
Color Camera |
分辨率 (MegaPixels) |
3.0 |
型号 |
PL-B623 |
相机系列 |
PL-B |
生产商 |
PixeLINK? |
是 |
|
RoHS |
符合标准 |
?
PL-B625 Color USB CMOS Camera for Microscopy
库存#64-237技术参数与相关资料
成像设备 |
ON Semi MT9P031 |
传感器类型 |
Progressive Scan CMOS |
感应区域，H x V (mm) |
4.5 x 2.88 |
像素 (H x V) |
2592 x 1944 |
像素大小，H x V (μm) |
2.2 x 2.2 |
像素深度 |
8 & 12 bit |
帧频 (fps) |
7 |
电子快门 |
0.1ms - 2s |
快门类型 |
Rolling |
信噪比 (dB) |
>60 |
摄像机控制 |
Via Software |
同步 |
External or Via Software |
视频输出 |
USB 2.0 |
振动额定值 |
300 G & 20 G (10 Hz - 2 KHz) |
震动额定值 |
50 G |
工作温度 (°C) |
0 to +50 |
功率要求 |
Via?#63-237?USB 2.0 Cable (Sold Separay) |
支架 |
C-Mount |
重量 (g) |
204 |
类型 |
Color Camera |
分辨率 (MegaPixels) |
5.0 |
型号 |
PL-B625 |
相机系列 |
PL-B |
生产商 |
PixeLINK? |
是 |
|
RoHS |
符合标准 |
?
PL-B681 Color USB CMOS Camera for Microscopy
库存#64-235技术参数与相关资料
成像设备 |
ON Semi IBIS 5B |
传感器类型 |
Progressive Scan CMOS |
感应区域，H x V (mm) |
8.6 x 6.9 |
像素 (H x V) |
1280 x 1024 |
像素大小，H x V (μm) |
6.7 x 6.7 |
像素深度 |
8/10 bit |
帧频 (fps) |
27 |
电子快门 |
0.04ms - 1s |
快门类型 |
Global |
信噪比 (dB) |
>54.6, >100 with Knee Points |
摄像机控制 |
Via Software |
同步 |
External or Via Software |
视频输出 |
USB 2.0 |
振动额定值 |
300 G & 20 G (10 Hz - 2 KHz) |
震动额定值 |
50 G |
工作温度 (°C) |
0 to +50 |
功率要求 |
Via?#63-237?USB 2.0 Cable (Sold Separay) |
支架 |
C-Mount |
重量 (g) |
204 |
类型 |
Color Camera |
分辨率 (MegaPixels) |
1.3 |
型号 |
PL-B681 |
相机系列 |
PL-B |
生产商 |
PixeLINK? |
是 |
|
RoHS |
符合标准 |
?
PL-B871 Color USB CCD Camera for Microscopy
库存#64-231技术参数与相关资料
成像设备 |
Sony ICX205 |
传感器类型 |
Progressive Scan CCD |
感应区域，H x V (mm) |
6.5 x 4.8 |
像素 (H x V) |
1392 x 1040 |
像素大小，H x V (μm) |
4.65 x 4.65 |
像素深度 |
8 & 12 bit |
帧频 (fps) |
10 |
电子快门 |
100μs - 10s |
快门类型 |
Inter Line Transfer |
信噪比 (dB) |
>60 |
摄像机控制 |
Via Software |
同步 |
External or Via Software |
视频输出 |
USB 2.0 |
振动额定值 |
300 G & 20 G (10 Hz - 2 KHz) |
震动额定值 |
50 G |
工作温度 (°C) |
0 to +50 |
功率要求 |
Via?#63-237?USB 2.0 Cable (Sold Separay) |
支架 |
C-Mount |
重量 (g) |
238 |
类型 |
Color Camera |
分辨率 (MegaPixels) |
1.4 |
型号 |
PL-B871 |
相机系列 |
PL-B |
生产商 |
PixeLINK? |
是 |
|
RoHS |
符合标准 |
?
PL-B873 Color USB CCD Camera for Microscopy
库存#64-233技术参数与相关资料
成像设备 |
Sony ICX274 |
传感器类型 |
Progressive Scan CCD |
感应区域，H x V (mm) |
7.0 x 5.3 |
像素 (H x V) |
1600 x 1200 |
像素大小，H x V (μm) |
4.4 x 4.4 |
像素深度 |
8 & 12 bit |
帧频 (fps) |
15 |
电子快门 |
54μs - 10s |
快门类型 |
Inter Line Transfer |
信噪比 (dB) |
>45 |
摄像机控制 |
Via Software |
同步 |
External or Via Software |
视频输出 |
USB 2.0 |
振动额定值 |
300 G & 20 G (10 Hz - 2 KHz) |
震动额定值 |
50 G |
工作温度 (°C) |
0 to +50 |
功率要求 |
Via?#63-237?USB 2.0 Cable (Sold Separay) |
支架 |
C-Mount |
重量 (g) |
238 |
类型 |
Color Camera |
分辨率 (MegaPixels) |
2.0 |
型号 |
PL-B873 |
相机系列 |
PL-B |
生产商 |
PixeLINK? |
是 |
|
RoHS |
符合标准 |
