Andover硬涂层宽带滤光片
我们的*个表面，硬涂层宽带滤光片采用磁控管溅射，硬氧化涂层沉积在硼硅酸盐玻璃上，不使用任何吸收滤光眼镜，使它们适用于高温应用。它们提供了一个从高峰传输到OD4阻塞的陡峭过渡。可用于标准拉曼波长:488,514,532,633,785nm，以及其他流行的波长。我们提供三个标准尺寸，可根据要求定制尺寸和环安装。
Andover硬涂层宽带滤光片
通用规格：
| 厚度： | 3.1±.0.25mm |
| 尺寸公差： | +0.0 / -0.2mm |
| 小通光孔径： | 95% of outside dimension |
| 基底材质： | Boroscilicate?Glass |
| 平坦度： | 3-5 waves |
| 表面质量： | 60-40 per MIL-C-48497A |
| 湿度和磨损： | Per MIL-C-67 |
| 耐久性： | Per MIL-C-48497A |
| 工作温度： | -50°C to +200°C |
| 机械： | Unmounted |
典型的光谱曲线:
订购信息：
| 描述 | 型号 |
| 345.0nm CWL, 80.0nm Bandwidth, 12.5 mm Diameter, Hard-Coated Broadband Filter | 345HC80-12.5 |
| 345.0nm CWL, 80.0nm Bandwidth, 25.0 mm Diameter, Hard-Coated Broadband Filter | 345HC80-25 |
| 345.0nm CWL, 80.0nm Bandwidth, 50.0 mm Diameter, Hard-Coated Broadband Filter | 345HC80-50 |
| 441.6nm CWL, 150.0nm Bandwidth, 12.5 mm Diameter, Hard-Coated Broadband Filter | 442HC150-12.5 |
| 441.6nm CWL, 150.0nm Bandwidth, 25.0 mm Diameter, Hard-Coated Broadband Filter | 442HC150-25 |
| 441.6nm CWL, 150.0nm Bandwidth, 50.0 mm Diameter, Hard-Coated Broadband Filter | 442HC150-50 |
| 470.0nm CWL, 100.0nm Bandwidth, 12.5 mm Diameter, Hard-Coated Broadband Filter | 470HC100-12.5 |
| 470.0nm CWL, 100.0nm Bandwidth, 25.0 mm Diameter, Hard-Coated Broadband Filter | 470HC100-25 |
| 470.0nm CWL, 100.0nm Bandwidth, 50.0 mm Diameter, Hard-Coated Broadband Filter | 470HC100-50 |
| 488.0nm CWL, 80.0nm Bandwidth, 12.5 mm Diameter, Hard-Coated Broadband Filter | 488HC80-12.5 |
| 488.0nm CWL, 80.0nm Bandwidth, 25.0 mm Diameter, Hard-Coated Broadband Filter | 488HC80-25 |
| 488.0nm CWL, 80.0nm Bandwidth, 50.0 mm Diameter, Hard-Coated Broadband Filter | 488HC80-50 |
| 514.5nm CWL, 90.0nm Bandwidth, 12.5 mm Diameter, Hard-Coated Broadband Filter | 515HC90-12.5 |
| 514.5nm CWL, 90.0nm Bandwidth, 25.0 mm Diameter, Hard-Coated Broadband Filter | 515HC90-25 |
| 514.5nm CWL, 90.0nm Bandwidth, 50.0 mm Diameter, Hard-Coated Broadband Filter | 515HC90-50 |
| 532.0nm CWL, 150.0nm Bandwidth, 12.5 mm Diameter, Hard-Coated Broadband Filter | 532HC150-12.5 |
| 532.0nm CWL, 150.0nm Bandwidth, 25.0 mm Diameter, Hard-Coated Broadband Filter | 532HC150-25 |
| 532.0nm CWL, 150.0nm Bandwidth, 50.0 mm Diameter, Hard-Coated Broadband Filter | 532HC150-50 |
| 550.0nm CWL, 300.0nm Bandwidth, 12.5 mm Diameter, Hard-Coated Broadband Filter | 550HC300-12.5 |
| 550.0nm CWL, 300.0nm Bandwidth, 25.0 mm Diameter, Hard-Coated Broadband Filter | 550HC300-25 |
| 550.0nm CWL, 300.0nm Bandwidth, 50.0 mm Diameter, Hard-Coated Broadband Filter | 550HC300-50 |
| 632.8nm CWL, 90.0nm Bandwidth, 12.5 mm Diameter, Hard-Coated Broadband Filter | 633HC90-12.5 |
| 632.8nm CWL, 90.0nm Bandwidth, 25.0 mm Diameter, Hard-Coated Broadband Filter | 633HC90-25 |
| 632.8nm CWL, 90.0nm Bandwidth, 50.0 mm Diameter, Hard-Coated Broadband Filter | 633HC90-50 |
| 785.0nm CWL, 170.0nm Bandwidth, 12.5 mm Diameter, Hard-Coated Broadband Filter | 785HC170-12.5 |
| 785.0nm CWL, 170.0nm Bandwidth, 25.0 mm Diameter, Hard-Coated Broadband Filter | 785HC170-25 |
| 785.0nm CWL, 170.0nm Bandwidth, 50.0 mm Diameter, Hard-Coated Broadband Filter | 785HC170-50 |
