16X精密变焦镜头
?16:1变焦比
?分辨率高、景深大
?手动光圈
?兼容Mitutoyo物镜
16X精密变焦镜头是个高品质模组视频镜头，分辨率高，景深大，用途广，放大倍率从0.063X到190X，工作距离可从370mm到13mm..
整个光学系统需要以下器件：C接口适配器，Dovetail管，前变焦组，后变焦组，物镜（MITUTOYO 适配器），40”光纤束等。光纤适配器可连接照明器件，安装方法可参见316页。可选环形光连接口(#56-215)和环形导光设备.
锲形管可调焦以保证等焦面。SENSOR大尺寸为1 /3” 可配０.５Ｘ的套管，SENSOR大尺寸为2/3”可配1.0X的锲形管。０.５Ｘ的调焦管不能与Mitutoyo物镜兼容，使用同轴照明以及２／３”SENSOR可以降低远场校正变焦范围，同时变焦范围也 有所降低
技术数据
Technical Information
16X Precision Zoom Lens |
|||||
Objectives |
Specifications |
Dovetail Tubes |
|||
0.5X |
1.0X |
||||
Low |
High |
Low |
High |
||
0.25X, 370mm WD |
NA |
0.0022 |
0.038 |
0.0022 |
0.038 |
PMAG |
0.063X |
1.0X |
0.13X |
2.0X |
|
DOF** |
108.8mm |
0.38mm |
108.8mm |
0.38mm |
|
FOV* |
76.8mm |
4.8mm |
51.2mm |
3.2mm |
|
1.0X, 89mm WD |
NA |
0.0090 |
0.15 |
0.0090 |
0.15 |
PMAG |
0.25X |
4.0X |
0.50X |
8.0X |
|
DOF** |
6.8mm |
0.024mm |
6.8mm |
0.024mm |
|
FOV* |
19.2mm*** |
1.2mm |
12.8mm |
0.80mm |
|
1.5X, 56mm WD |
NA |
0.014 |
0.23 |
0.014 |
0.23 |
PMAG |
0.38X |
6.0X |
0.75X |
12.0X |
|
DOF** |
3.0mm |
0.011mm |
3.0mm |
0.011mm |
|
FOV* |
12.8mm*** |
0.80mm |
8.5mm |
0.53mm |
|
2.0X, 37mm WD |
NA |
0.018 |
0.30 |
0.018 |
0.30 |
PMAG |
0.50X |
8.0X |
1.0X |
16.0X |
|
DOF** |
1.7mm |
0.0060mm |
1.7mm |
0.0060mm |
|
FOV* |
9.6mm*** |
0.60mm |
6.4mm*** |
0.40mm |
|
16X Precision Zoom Lens + Mitutoyo objectives |
||
Mitutoyo Objectives |
Limited FOV Range* (mm) |
Min. Zoom Setting for Even Illumination |
5X |
1.0 - 0.33 |
2.5X |
20X |
0.21 - 0.084 |
3.25X |
50X |
0.063 - 0.033 |
4.25X |
订购信息
标题 |
产品号 |
|---|---|
C-Mount Coupler for 16X Precision Zoom Lens |
#56-203 |
0.5X Dovetail Tube for 16X Precision Zoom Lens |
#56-204 |
1.0X Dovetail Tube for 16X Precision Zoom Lens |
#56-205 |
Manual Upper Zoom Module for 16X Precision Zoom Lens |
#56-219 |
Plain Lower Module Objective for 16X Precision Zoom Lens |
#56-207 |
Coaxial Illumination Lower Module w/ 5mm Focus for 16X PZL |
#56-220 |
Focusable Lower Module w/ 15mm Fine Focus for 16XPZL |
#59-698 |
Motorized Focusable Lower Module w/ 15mm Focus for 16X PZL |
#56-971 |
1.50X Objective for 16X Precision Zoom Lens |
#56-212 |
Mitutoyo Objective Adapter for 16X Precision Zoom Lens |
#56-214 |
附件
标题 |
产品号 |
|---|---|
Additional 230V Power Supply For Motor Driver |
#57-825 |
40" Flexible Fiber Optic Bundle |
#59-686 |
