| 品牌 |
康普 |
型号 |
1427071-6 |
| 包装 |
箱 |
零件状态 |
在售 |
| 类型 |
六类线/CAT6 |
材料 |
无氧铜 |
| 安装类型 |
用户自定义 |
最小包装量 |
1 |
| 屏蔽层 |
非屏蔽双绞线 |
线芯材质 |
裸铜线 |
| 护套材质 |
PVC |
纤芯绞合方式 |
对绞 |
| 传输速率 |
1000Kpbs |
抗拉强度 |
35N |
| 芯数 |
8 |
使用温度 |
0℃~60℃ |
| 批号 |
2023 |
抗压强度 |
30N |
| 适用范围 |
布线,弱电,机房 |
产品认证 |
UL |
| 数量 |
1 |
封装 |
是 |
23423436546
| 2423435345345dc Resistance, maximum | 9.38 ohms/100 m | 2.859 ohms/100 ft |
| Delay Skew, maximum | 45 ns |
| Dielectric Strength, minimum | 1500 Vac | 2500 Vdc |
| Mutual Capacitance at Frequency | 5.6 nF/100 m @ 1 kHz |
| Nominal Velocity of Propagation (NVP) | 68 % |
| Operating Frequency, maximum | 250 MHz |
| Operating Voltage, maximum | 80 V |
| Propagation Delay, maximum | 536 ns/100m @250MHz |
| Remote Powering | Fully complies with the recommendations set forth by IEEE 802.3bt (Type 4) for the safe delivery of power over LAN cable when installed according to ISO/IEC 14763-2, CENELEC EN 50174-1, CENELEC EN 50174-2 or TIA TSB-184-A564545453 |
Electrical Cable PerformanceCSCommScopeStdRefers to the standard value listed under Transmission Standards in the Electrical Specifications aboveTypTypicalILInsertion Loss (dB/100m)NEXTNear End Crosstalk (dB/100m)ACRAttenuation to Crosstalk Ratio (dB/100m))PSNEXTPower Sum Near End Crosstalk (db/100m)PSACRPower Sum Attenuation to Crosstalk Ratio (dB/100m)ACRFAttenuation to Crosstalk Ratio - Far End (dB/100m)PSACRFInsertion Loss (dB/100m)RLReturn Loss (dB)
| Frequency | IL, STD | NEXT, STD | ACR, STD | PSNEXT, STD | PSACR, STD | ACRF, STD | PSACRF, STD | RL, STD | TCL, STD | ELTCTL, STD |
| 1.00 MHz | 2.0 | 74.3 | 72.3 | 72.3 | 70.3 | 67.8 | 64.8 | 20.0 | 40.0 | 35.0 |
| 4.00 MHz | 3.8 | 65.3 | 61.5 | 63.3 | 59.5 | 55.8 | 52.8 | 23.0 | 40.0 | 23.0 |
| 8.00 MHz | 5.3 | 60.8 | 55.4 | 58.8 | 53.4 | 49.9 | 46.9 | 24.5 | 40.0 | 16.94534534534 |
4354324234324
Electrical SpecificationsCharacteristic Impedance
100 ohmdc Resistance Unbalance, maximum
5 %dc Resistance, maximum
9.38 ohms/100 m | 2.859 ohms/100 ftDelay Skew, maximum
45 nsDielectric Strength, minimum
1500 Vac | 2500 VdcMutual Capacitance at Frequency
5.6 nF/100 m @ 1 kHzNominal Velocity of Propagation (NVP)
68 %Operating Frequency, maximum
250 MHzOperating Voltage, maximum
80 VPropagation Delay, maximum
536 ns/100m @250MHzRemote Powering
Fully complies with the recommendations set forth by IEEE 802.3bt (Type 4) for the safe delivery of power over LAN cable when installed according to ISO/IEC 14763-2, CENELEC EN 50174-1, CENELEC EN 50174-2 or TIA TSB-184-A
