玖城牌电子触点润滑脂
产品型号:cg3501 cg3502 cg3503
产品描述:玖城牌电子触点润滑脂采用合成酯基础油、特种稠化剂为基础,添加特殊添加剂经特殊的工艺精制而成。
产品特点:
高粘度指数、极优的附着力,优异的润滑防护确保极优的平滑、安静操纵感。
极优抗氧化性:优秀的化学稳定性,抗氧化、抗磨损、防锈蚀、确保接触点。
极优触感:有效防止碳化、改善开关的触感显著提高电气接触性能。
极优适应性:有效灭弧防止产生电火花、极端的温度条件下持续、有效工作。
产品应用:
各种线性接点润滑及防腐蚀。
微动开关、电位器、可变电阻器、轻触开关、按钮开关、声光控制开关。
继电器、编码元件的电接触表面的润滑和提高通电性能。
使用温度:-30℃~150℃
jc electronic contact grease
product number:cg3501 cg3502 cg3503
product deion:
jc electronic contact grease,manufactured by special thickening agent and base oil of synthetic ester ,add the special additives are refined by special process.
performance characteristics:
with excellent high viscosity index, excellent adhesion, excellent lubrication protection ensures excellent smooth, quiet operation
with excellent oxidation resistance: excellent chemical stability, anti-oxidation, anti-wear, anti-corrosion, ensure contact point.
with excellent touch: effectively prevents carbonization, improves touch sensitivity of switches, and significantly improves electrical contact performance.
with excellent adaptability: effective arc extinguishing to prevent generating electric sparks, and continuous and effective work under extreme temperature conditions.
recommended use:
used for all kinds of linear contact point lubrication and corrosion protection.
used for micro switch, potentiometer, variable resistor, touch switch, button switch, acousto-optic control switch.
used for the electrical contact surface of the relay and the coding element is lubricated and the electrical performance is improved.
temperature range:-30℃ to 150℃
玖城牌电子触点润滑脂的典型数据:typical data of jc electronic contact grease:
项目project
|
典型数据typical data
|
|
外观 appearance
|
白色均匀油膏
|
|
工作锥入度/0.1mm 60次 penetration 1/10mm 60 times
|
235--285
|
|
滴点,℃ drop point,℃
|
330
|
|
铜片腐蚀(t2.100℃.24h) copper corrosion(t2.100℃.24h)
|
合格pass
|
|
水淋流失量(79℃,1h)% sprinkling loss(79℃,1h)%
|
1.3
|
|
钢网分油(100℃,24h)% steel mesh oil filtering(100℃,24h)%
|
1.5
|
|
防腐蚀性(52℃,48h) corrosion resistance(52℃,48h)
|
合格 pass
|
|
极压性能(四球机法)pa/kg extreme pressure performance (4-ball test)pa/kg
|
480
|
|
抗磨性能(四球机法)(40kg,60min)/mm antiwear performance (4-ball test)(40kg,60min)/mm
|
0.44
|
|
emcor防锈实验,10%合成海水 emcor antirust experiment, 10% synthetic sea water
|
0.0(无锈) (no rust)
|
|
适用工作温度℃ applicable working temperature ℃
|
-30--+150
|
