联系人:杨明安
邮箱:sn@jssenen.com
电话:15805143879
地址: 江苏南京市六合区化学工业园区天圣路111号
| 型号 |
WSS-411S/413S/414S/415S |
工作原理 |
双金属温度计 |
| 测量方式 |
接触式 |
显示方式 |
指针 |
| 安装形式 |
支撑式安装 |
测量单位 |
摄氏度℃ |
| 加工定制 |
是 |
测量精度 |
1.5 |
一、产品简介 Product Brief
WSS系列双金属温度计其保护管、节头、锁紧螺栓等均采用1Cr18Ni9Ti材料,表壳采用铝板拉伸成型经切削加工表面黑色电泳处理,表盖与表盒采用环型双层橡胶圈螺纹密封锁紧结构,故仪表整体防水防腐性能良好,径向型仪表采用弯管型结构,外型新颖、轻巧、美观与众不同。
The company's production WSS series Double metal thermometer The protective tube, Section head, The locking bolt Adopt 1Cr18Ni9Ti Material, Case features Aluminum sheet stretch forming Cutting machining Black surface electrophoresis processing, Table with the table box cover Using ring double layer rubber ring Thread sealing locking structure, The meter overall waterproof anti-corrosion performance is good, Radial type instrument Using the pipe type structure, Novel appearance, lightweight, beautiful out of the ordinary.
WSS系列双金属温度计是用于测量中、低温的现场检测仪表,可以用来直接测量气体和液体的温度。与玻璃为温度计相比具有无汞害、读数直观、牢固耐用、多种结构形式、可满足不同要求等优点。
WSS series double metal thermometer is used for measuring, in low temperature The on-site detection instruments, Can be used for direct measurement of gas and liquid Temperature. With mercury in glass thermometer compared with no harmful hg, Intuitive readings, firm and durable, various structural forms, Can meet different requirements Etc..
