  C2-2855,广电多格式转换器

  Key Features of the C2-2855

  Up/Down/Cross Conversion

  Digital Inputs: SD/HD/3G-SDI, DVI-U*, HDMI (DVI 1.0, HDCP 1.4)

  Analog Inputs: YUV/YPbPr, RGB/YPbPr, CV, YC

  Digital Outputs: SD/HD/3G-SDI, DVI-U*, HDMI (DVI 1.0, HDCP 1.4)

  Analog Outputs: DVI-U* (RGB/YPbPr/YUV), CV, YC

  Analog: PC to 1920x1080, HDTV to 1080p/60

  HDMI & DVI : PC to 1920x1200, HDTV to 1080p/60

  Supports: NTSC, PAL, PAL-M, PAL-N

  Motion Compensation & 3:2 Pulldown

  Temporal Interpolation & Diagonal Interpolation

  Automatic Incoming Resolution Detection

  Auto-Set Calibrate - Automatic picture sizing of PC inputs

  Auto-Switching – Automatically switch between connected inputs

  4:4:4 Full bandwidth Chroma Sampling for RGB sources

  4:2:2 for SDI, YC and CV sources

  HDMI YUV support for either 4:4:4 or 4:2:2 sampling

  Video signal parameter adjustments

  Integral 4x1 Stereo Analog Audio Routing Switcher, fully integrated with digital audio

  Stereo Audio Embedding on capable outputs (DVI-U*, HDMI, SDI)

  RS-232 and IP Interface for Control Software

  Variable Image Zoom to 10X and Shrink to 10%

  Genlock

  Framelock

  PIP, Chromakey and Lumakey

  Optional Single/Dual Rackmount Kit
