C2-2855多格式转换器

　　C2-2855,广电多格式转换器

　　Key Features of the C2-2855

　　Up/Down/Cross Conversion

　　Digital Inputs: SD/HD/3G-SDI, DVI-U*, HDMI (DVI 1.0, HDCP 1.4)

　　Analog Inputs: YUV/YPbPr, RGB/YPbPr, CV, YC

　　Digital Outputs: SD/HD/3G-SDI, DVI-U*, HDMI (DVI 1.0, HDCP 1.4)

　　Analog Outputs: DVI-U* (RGB/YPbPr/YUV), CV, YC

　　Analog: PC to 1920x1080, HDTV to 1080p/60

　　HDMI & DVI : PC to 1920x1200, HDTV to 1080p/60

　　Supports: NTSC, PAL, PAL-M, PAL-N

　　Motion Compensation & 3:2 Pulldown

　　Temporal Interpolation & Diagonal Interpolation

　　Automatic Incoming Resolution Detection

　　Auto-Set Calibrate - Automatic picture sizing of PC inputs

　　Auto-Switching – Automatically switch between connected inputs

　　4:4:4 Full bandwidth Chroma Sampling for RGB sources

　　4:2:2 for SDI, YC and CV sources

　　HDMI YUV support for either 4:4:4 or 4:2:2 sampling

　　Video signal parameter adjustments

　　Integral 4x1 Stereo Analog Audio Routing Switcher, fully integrated with digital audio

　　Stereo Audio Embedding on capable outputs (DVI-U*, HDMI, SDI)

　　RS-232 and IP Interface for Control Software

　　Variable Image Zoom to 10X and Shrink to 10%

　　Genlock

　　Framelock

　　PIP, Chromakey and Lumakey

　　Optional Single/Dual Rackmount Kit
