　　Handheld through hole copper thickness gage mm610

　　Milum mm610 is rechargeable battery

　　operated handheld PCB through hole

　　copper thickness measuring gage.

　　Measures over 30 mil PCB board

　　thickness and above 35mil hole

　　diameter through hole Copper plated

　　thickness of etched and before etched

　　boards.

　　Unique design and simple operating

　　display allows the user to understand

　　everything fully at a glance.

　　Eddy current principle

　　Multifunction clear display, simple to operate

　　Backlight bright LCD display

　　Compensation feature to meet product standard

　　Set High and Low limits to detect when out of

　　specification

　　Simple to use and convenient to carry around

　　Measures in mil or um

　　Single standard Calibration

　　Quick push and pull probe connector design.

　　Replaceable probe tip design

　　USB interface for computer download

　　Rechargeable long life battery, economic and

　　environmental

　　Optimum design using simple and friendly

　　Operating interface

　　Specification

　　Measuring range 0.04~8mil (1~200um)

　　Accuracy +/- 3% (according to the standard)

　　Resolution 1- 3 digits ( fixed )

　　Minimum hole diameter 35mil (0.9mm)

　　Minimum board thickness 30mil. (0.75mm)

　　Memory 20,000 readings

　　Dimension (L) 130mm /(w) 70mm /(H) 30mm

　　Export interfaces USB

　　Weight 210 grams

　　Battery 9 V rechargeable battery, AC adapter included

　　Life-span of the battery Can be used again after recharging
