产品介绍 Introduction

　　智能装车机器人是一种集挖掘、破碎、装载于一体的高效智能生产设备，主要用于矿山斜巷平巷、铁路隧 道施工和***洞窟等施工中的采掘、装载与抢险作业。

　　机器人靠履带推进及铲斗采掘扒取矿石送入自身皮带输送机，并从输送机尾部将矿石卸入矿车或其他运载设备。同时可利用挖掘臂铲斗扒取远处的岩石，也可以用铲斗来清理工作面，实现全断面***工作界面，***的提高了采掘及装载效率，并降低了作业人员的劳动强度，具有结构紧凑﹑机动灵活等特点，可在狭窄、潮湿、危险 的巷道里工作。

　　机器人采用全操作工作模式，可以实现***作业人员远离采掘工作面，作业更安全，大大降低 了工作危害性。

主要技术特点 Main technical features

　　智能作业 整机操控实现全自动化，无线安全操作，有效避免或降低近距离作业时恶劣工况对人身的伤害。

　　Intelligent remote control operation The control of the whole unit is fully automatic,safe to operate by the wireless remote control, which can effectively avoid or reduce the personal injury caused by the harsh working conditions during short-distance operation.

　　同时具有和手动应急操作功能 电控箱有和本机控制两种模式，正常生产作业时采用模式。作业人员实现远距离(≤30米)操作 器进行生产作业，作业人员在模式下操作扩展了其现场作业的视野范围，提高了其现场操作的灵活性，有效 提升了现场的安全系数。

　　It has remote control and manual emergency operation functions at the same time The electric control box has two modes of remote control and local control,and the remote control mode is used in normal production operations.The operator can operate the remote control from a long distance (≤30 meters), which expands the scope of field operation,improves the flexibility of site working, and effectively improves the safety factor of the field.

　　采用静液压动力操控系统 采用电磁比例静液压动力操控系统，使整机操控更加***、随动、灵活。

　　Hydrostatic power control system The electromagnetic proportional hydrostatic power control system is adopted to make the control of the whole machine more precise, movable and flexible.

　　破岩能力强 依靠钢制履带行走，推力大，动力强劲，挖取方位广，全断面装岩，不留死角，无需人工辅助清理工作面。岩石 的普氏硬度f小于等于12，块度小于等于400mm，松散密度不大于1.8t/m3 。

　　Strong rock breaking ability Relying on the steel crawler to travel, large thrust ,strong power,wide digging direction, whole-section loading with no dead ends left, and no manual assistance required to clean the working face. The rock Platts hardness f is less than or equal to 12, rock lumpiness less than or equal to 400mm, and the loose density not more than 1.8t/m3 .
