蓝牙WIFI双控尼龙电磁阀 蓝牙远程自动浇水电磁阀

　　RETZ/我们一直致力于流体控制领域的持续创新，始于2005……

　　进口蓝牙电磁阀采用手机远程控制器是智能生活APP中的一款智能浇灌产品，采用蓝牙模组，通过APP使设备与路由器建立通讯，实现手机智能控制retz The imported Bluetooth solenoid valve uses a mobile phone remote controller, which is an intelligent irrigation product in the smart life app. It uses a Bluetooth module to establish communication between the device and the router through the app, achieving intelligent control of the mobile phone

　　规格Specification:1/2～6"

　　适用温度Temperature：≤60℃

　　压力范围Pressure Range：1.0-8 bar

　　工作流量：500~1700L/h Working flow rate: 500~1700L/h

　　供电：9V干电池，额定功耗：<1W ,静态电流：30mA

　　输出控制方式：脉冲输出

　　防水等级：IP67

　　使用范围：蓝牙覆盖范围内

　　连接方式Connection method：螺纹，法兰连接Thread, flange connection

　　材料：阀体-尼龙

　　密封件-NBR/EPDM

　　动铁芯-430F

　　静铁芯-430F

　　弹簧-SUS304

　　紫铜分磁环

　　技术参数Technical parameter

　　1.手动开关: Manual switch进口蓝牙电磁阀2.jpg

　　开关按键 手动开关控制器，长按5秒可进入手机配对模式The switch button manually switches the controller on and off. Press and hold for 5 seconds to enter the phone pairing mode

　　单击手动按键即可控制设备开启关闭状态，设备处于自动（开关按键长按可重置设备，浇灌模式时手动开关失效。重新配对，重置后设备处于未绑定未连接状态）Click the manual button to control the device to turn on or off, and the device is in automatic mode. (Press and hold the switch button to reset the device, but the manual switch fails during pouring mode. After pairing again, the device is in an unbound and unconnected state after resetting.)

　　2.状态灯:当设备开启时，状态灯会亮起1秒Status light: When the device is turned on, the status light will light up for 1 second

　　3.配置灯: Configure Lights

　　A、当蓝牙处于绑定、连接状态，长亮3秒后熄灭When Bluetooth is in a bound and connected state, it remains on for 3 seconds and then turns off

　　B、当蓝牙处于绑定未连接状态，1秒间隔闪烁3次When Bluetooth is in a bound unconnected state, it flashes 3 times every 1 second

　　C、当蓝牙处于未绑定未连接状态，快闪9次。When Bluetooth is in an unbound and disconnected state, flash 9 times
