进口卫生级伺服电机驱动转子泵

　　进口卫生级伺服电机驱动转子泵设计有多种配置，其中分为标准配置，全不锈钢配置，是一款正位移凸轮转子泵，是根据美国3A-02-11严格卫生要求设计的，非常适合于食品加工，饮料、果汁、乳制品、化妆品、制药工业等各种高粘稠和低粘稠物料的输送，也可以输送含有固体颗粒物料，还可以应用在CIP和SIP系统上。进口卫生级伺服电机驱动转子泵还具有其他容积泵所不具备的性能，如低脉冲现象、高压力、旋转双向可逆、灵活功能组合retz The imported sanitary servo motor driven rotor pump is designed with various configurations, including standard configuration and all stainless steel configuration. It is a positive displacement cam rotor pump designed according to the strict hygiene requirements of 3A-02-11 in the United States. It is very suitable for conveying various high and low viscosity materials such as food processing, beverages, juice, dairy products, cosmetics, pharmaceutical industries, and can also transport materials containing solid particles, It can also be applied to CIP and SIP systems. This pump also has performance that other volumetric pumps do not have, such as low pulse phenomenon, high pressure, reversible rotation, and flexible functional combinations

　　进口卫生级伺服电机驱动转子泵选型参数

　　流量Max.flow：90m3/ h / 395 GPM

　　压力Max.pressure：15bar / 220 Psi

　　温度Max.Temperature：150℃/ 302℉

　　转速Max.rev：750 rpm

　　材质：316L，1.4404，ASME BPE 316L，1.4435NB2Fe≤0.5％

　　表面处理：表面处理：≤Ra0.8μm，≤Ra0.6μm，≤Ra0.4μm
