进口卫生级伺服电机驱动螺杆泵

　　RETZ瑞茨/我们一直致力于高精度流量测量领域的持续创新，始于2005……

　　进口伺服电机驱动螺杆泵具有较强的自吸能力和可输送含有固体颗粒、气液混合物、高粘稠、低粘稠等各种复杂工况及物料输送和抽取；它不但用于物料抽取和输送，也可应用在CIP和SIP系统上，可减少管路、阀门控制、CIP专用泵，这样不仅提高效率、且可以降低成本。进口伺服电机驱动螺杆泵还具有其他容积泵所不具备的性能，如，无脉冲现象、颗粒无破损、高压力、转速范围广、流量范围大等特点retz The imported servo motor driven screw pump has strong self-priming capacity and can transport various complex working conditions including solid particles, gas-liquid mixture, high viscosity, low viscosity and other materials, as well as material transportation and extraction; It is not only used for material extraction and transportation, but also can be applied to CIP and SIP systems, reducing pipeline, valve control, and CIP specialized pumps, which not only improves efficiency but also reduces costs. This pump also has performance that other volumetric pumps do not have, such as no pulse phenomenon, no particle damage, high pressure, wide speed range, and large flow range

　　进口伺服电机驱动螺杆泵选型参数

　　流量（Max flow） ：110m3/h

　　颗粒（Max Particles）：23mm

　　压力（Max pressure）：20bar

　　转速范围（Speed range）：10-3500 R.P.M

　　工作温度（Max Temperature）:-40℃ to 150℃

　　表面处理（Surface treatment）：Ra≤0.6μm；EP=Ra0.4μm

　　材质（Material） ：全不锈钢，介质接触部分316L
